LCP-500P-L

500W 1000W Air-cooled Pulsed Fiber Laser Cleaning Machine

Products Overview Our 500W pulsed laser cleaning machine is an advanced industrial surface treatment solution designed for high-power, high-precision contaminant removal. Utilizing state-of-the-art pulsed fiber laser technology (1064nm), it emits high-energy pulses to vaporize or ablate rust,...

Products Overview

Our 500W 1000W pulsed laser cleaning machine is an advanced industrial surface treatment solution designed for high-power, high-precision contaminant removal. Utilizing state-of-the-art pulsed fiber laser technology (1064nm), it emits high-energy pulses to vaporize or ablate rust, paint, oxides, oil, coatings, and welding residues without damaging the substrate.

Compared to sandblasting, chemical cleaning, and manual grinding, it is a clean and environmentally friendly alternative, requiring no consumables, reducing secondary waste, and minimizing environmental impact.


Key Advantages

✅ High Efficiency & Power
500W/1000W output delivers fast cleaning, wide scan width (up to 100mm), and high pulse energy for stubborn contaminants.

✅ Non-Abrasive & Non-Contact
No physical contact-preserves base material integrity, no deformation, no scratches.

✅ Eco-Friendly & Cost-Saving
No chemicals, no abrasives, no water. Zero waste, low maintenance, long lifespan.

✅ Precise & Controllable
Adjustable power (0–100%), frequency, pulse width. Selective cleaning on delicate or complex surfaces.

✅ Safe & Easy to Operate
Intelligent control, emergency stop, ergonomic handheld cleaning head (1.05kg).

✅ Versatile & Wide Application
Works on metal (steel, aluminum, copper), alloys, composites, molds, tools, large components.

Laser Cleaning Machine Specifications

Specification QYCL-FP500 QYCL-FP500A QYCL-FP1000A
Average laser power (W) 500 1000 —
Single pulse energy (mJ) 1.5 2 5 / 15
Laser Brand JPT MAX / GZ MAX / JPT / GZ
Type of laser source Pulse laser
Output fiber type QBH QCS / QBH QBH
Central wavelength (nm) 1060 ~ 1070
Rated power (W) 2.5 4 —
Power adjustment range (%) 10 ~ 100
Focal distance (mm) 100 / 160 / 254 / 330 / 420
Cooling method Air Cooling
Fiber length (m) 5 5 / 10 10
Weight of machine (kg) 27 ± 2 38 ± 2 —
Dimension of machine (mm) 540 × 390 × 560 585 × 419 × 679 —
Working temperature (°C) 0 ~ 40
Voltage (V) 220
Note: The table uses “—” where the supplied specifications did not clearly provide a model-specific value.

Compared to Traditional Cleaning

Feature Laser Cleaning Sandblasting Chemical Cleaning Manual Grinding
Damage to Substrate None High Medium High
Consumables Yes Yes Yes Yes
Waste / Pollution None High Toxic High
Precision High (μm level) Low Medium Low
Speed Very Fast Fast Slow Slow
Cost (Long Term) Very Low High High High
Eco-Friendly ✅ Yes ❌ No ❌ No ❌ No

Included With Purchase

lasercleanexpert

Laser Cleaning Safety Glasses

lasercleanexpert

Quick Reference Parameter Guide

lasercleanexpert

1/2 Day Remote Training

Schedule a Remote Demo Today
Let our technicians show you the power of laser surface cleaning.
Schedule Today

Product Warranty

The warranty period of this product is one year for the whole machine, and the warranty period for the laser source is two years:

  1. From the date of purchasing this product, our company provides a free warranty within one year. If the machine needs to be returned to the factory for repair, the user only needs to bear the cost of two-way transportation.
  2. This product is repaired free of charge for life, and the user only needs to bear the cost of spare parts and two-way transportation.

NOTE: The date of purchase is based on the invoice date or the date of receipt of the order.

The following scopes are not covered by warranty:

  1. Damage caused by improper use such as violent bumping, bending, etc.
  2. Human-caused damage.
  3. Laser accessories and consumables are not guaranteed (collimating mirrors, galvanometers, field mirrors and other optical parts, integrated cables, etc. are not covered by the warranty).
